Felicity IVEM5048 3000VA Inverter

The Felicity IVEM5048 is an inverter with 3000VA 5000VA rated output. Every figure on this page is taken from the manufacturer's datasheet for the IVEM5048.

Rated Output Power(VA): 3000VA 5000VA
Rated Output Power(W): 3000W 5000W
Nominal DC Input Voltage: 24V 48V

1 AEDTTC

Aperçu

The Felicity IVEM5048 is an inverter with 3000VA 5000VA rated output. Every figure on this page is taken from the manufacturer's datasheet for the IVEM5048.

Spécifications complètes

Caractéristiques électriques

Rated Output Power(VA)	3000VA 5000VA
Rated Output Power(W)	3000W 5000W
Nominal DC Input Voltage	24V 48V
Nominal Input Frequency	50Hz/60Hz (Auto detection)
Efficiency(Line Mode)	>95% (Rated R load, battery full charged)
Pass Through Without Battery	Yes
Nominal Input Voltage	230Vac
Input Voltage Range	90-280Vac
Max. Charge Current	100A
Over Charge Protection	Yes
Max. PV Open Circuit Voltage	500V
Max. Input Power	4000W 6000W
Max. Solar Charging Current	100A 100A
Max. Charging Current(PV+Grid)	100A 100A
Max. Input Current	15A 20A
Min. Startup Voltage	125V
Output Voltage Waveform	Pure sine wave
Nominal Output Voltage	230Vac+5%
Nominal Output Frequency(Hz)	50±0.3Hz/60Hz±0.3Hz(Adjustable)
Parallel capability	Yes, up to 12 units No
Peak Efficiency	93%
Surge Rating	2* rated power for 5s
Capable of Starting Electric	Yes
Output Short Circuit Protection	Yes

Caractéristiques mécaniques

Net Weight(KG)	9.1KG 11.2KG
Gross Weight(KG)	10.8KG 13.2KG
Product Dimension (MM)	395295129MM 415320129MM
Package Dimension (MM)	472372202MM 494399202MM
