Felicity IVEM3024 3 kVA Off-Grid Inverter

The Felicity IVEM3024 is an off-grid inverter with 3000VA rated output. Every figure on this page is taken from the manufacturer's datasheet for the IVEM3024.

Rated Output Power(VA): 3000VA
Rated Output Power(W): 3000W
Nominal DC Input Voltage: 24V

1 AEDشامل الضريبة

نظرة عامة

The Felicity IVEM3024 is an off-grid inverter with 3000VA rated output. Every figure on this page is taken from the manufacturer's datasheet for the IVEM3024.

المواصفات الكاملة

المواصفات الكهربائية

Rated Output Power(VA)	3000VA
Rated Output Power(W)	3000W
Nominal DC Input Voltage	24V
Nominal Input Voltage	230Vac
Max. AC Input Voltage	280Vac
Nominal Input Frequency	50Hz/60Hz (Auto Detection)
Efficiency(Line Mode)	>95% (Rated R Load, Battery Full Charged)
Pass Through Without Battery	Yes Utility Charge Mode Specifications
Input Voltage Range	90-280Vac
Max. Charge Current	100A
Over Charge Protection	Yes Solar Charging & Grid Charging
Max. PV Open Circuit Voltage	500V
Max. Input Power	4000W
Max. Solar Charging Current	100A
Max. Charging Current(PV+Grid)	100A
Max. Input Current	15A
Min. Startup Voltage	125V Inverter Mode Specifications
Output Voltage Waveform	Pure Sine Wave
Nominal Output Voltage	230Vac+5%
Nominal Output Frequency (Hz)	50±0.3Hz/60Hz±0.3Hz(Adjustable)
Parallel Capability	No
Peak Efficiency	93%
Surge Rating	2*
Capable of Starting Electric	Yes
Output Short Circuit Protection	Yes General Specifications
