Felicity MJS

Felicity FLH48100UG1 5.12KW LiFePO4 Battery Pack

The Felicity FLH48100UG1 is a lifepo4 battery pack with 5.12KWh of usable storage, a 51.2V nominal bus, ➤ 6000 rated.

Nominal Energy: 5.12KWh
Nominal Voltage: 51.2V
Nominal Capacity: 100Ah

1 AEDشامل الضريبة

نظرة عامة

The Felicity FLH48100UG1 is a lifepo4 battery pack with 5.12KWh of usable storage, a 51.2V nominal bus, ➤ 6000 rated. Every figure on this page is taken from the manufacturer's datasheet for the FLH48100UG1.

المواصفات الكاملة

المواصفات الكهربائية

Nominal Energy	5.12KWh
Nominal Voltage	51.2V
Nominal Capacity	100Ah
Number of Battery Modules	4(Min)
System Nominal Energy	20.48kWh 40.96kWh 61.44kWh
System Nominal Voltage	204.8V 409.6V 614.4V
System Operating Voltage	192-230.4V 384-460.8V 576-691.2V
Max. Continuous Charge/Discharge Current	100A
Peak Charge/Discharge current (155)	120A
Depth of Discharge(DOD)	≥ 95%
Cycle Life	➤ 6000
Battery Designation	IFPP/54/150/120/[(1P16S) NS] M/-20+50/95

المواصفات الميكانيكية

Product Dimension	560x590x1565.5MM (9th Floor)
Package Dimension	168×642×1570MM FLH48100R9G1
Gross Weight	45.0 kg
Net Weight	41.3 kg

المواصفات البيئية

IP Rating of Enclosure	IP21 Charge:0~+55°C
Operating Temperature Range	Discharge:-20°C~+55°C
Storge Temperature Range	0°C~+35°C
Humidity	5%~95%
Altitude	<2000M
